| General specifications |
| I/O Connectors |
Analog Input |
1 Mic/Line Combo, 1 TRS *Input 2 supports Hi-Z |
2 Mic/Line Combo *Input 2 supports Hi-Z |
2 Mic/Line Combo inputs *Hi-Z switch on input 2 for electric guitar |
4 Combo inputs (2 Mic/Hi-Z, 2 Mic/Line) + 2 TRS inputs |
| Analog Output |
2 TRS |
2 TRS |
2 TRS |
4 TRS |
| USB TO HOST |
1 (USB Type-C, 24-bit) |
1 (USB Type-C, 24-bit) |
1 (USB Type-C, 32-bit) |
1 (USB Type-C, 32-bit) |
| Phones |
1 TRS (40 mW+40 mW @40 Ohm) |
1 TRS (40 mW+40 mW @40 Ohm) |
1 TRS (15 mW+15 mW @40 Ohm) |
2 TRS (100 mW+100 mW @40 Ohm) |
| DC |
2 (Type-C USB bus power or Type-C USB DC IN) |
2 (Type-C USB bus power or Type-C USB DC IN) |
2 (Type-C USB bus power or Type-A micro-USB DC IN) |
2 (Type-C USB bus power or Burrel type DC IN) |
| MIDI |
- |
- |
1 IN / 1 OUT |
1 IN / 1 OUT |
| User Interface |
Input Gain, Mute, +48 V phantom power, Monitor switch, Volume (Main/Headphones) |
Input Gain, Mute, +48 V phantom power, Monitor switch, Main Volume, Headphones Volume |
Dedicated software "dspMixFx", Input Gain, Mono/Stereo switch, Hi-Z for Input 2, +48V phantom power, Mix balance, Main Volume, Headphones Volume |
Dedicated software "dspMixFx", Input Gain, +48V phantom power, Mix balance, Main Volume, Headphones Volume |
| Recording & Playback |
USB |
2-track recording, 2-track playback |
2-track recording, 2-track playback |
2-track recording, 2-track playback |
6-track recording, 4-track playback |
| Sampling frequency rate |
192 kHz - 44.1 kHz |
192 kHz - 44.1 kHz |
192 kHz - 44.1 kHz |
192 kHz - 44.1 kHz |
| Frequency response |
+0.0/-0.3 dB (20 Hz to 20 kHz) |
+0.0/-0.3 dB (20 Hz to 20 kHz) |
+0.0/-0.4 dB (20 Hz to 22 kHz) |
+0.0/-0.4 dB (20 Hz to 22 kHz) |
| Total harmonic distortion |
[MIC/LINE/Hi-Z] 0.004 % at 1 kHz, 20 kHz LPF; [MAIN OUTPUT] 0.004 % at 1 kHz, 20 kHz LPF |
[MIC/LINE/Hi-Z] 0.004 % at 1 kHz, 20 kHz LPF; [MAIN OUTPUT] 0.004 % at 1 kHz, 20 kHz LPF |
[MIC/LINE/Hi-Z] 0.003 % at 1 kHz, 22 Hz/22 kHz BPF; [MAIN OUTPUT] 0.002 % at 1 kHz, 22 Hz/22 kHz BPF |
[MIC/LINE/Hi-Z] 0.003 % at 1 kHz, 22 Hz/22 kHz BPF; [LINE IN 5-6] 0.002 % at 1 kHz, 22 Hz/22 kHz BPF; [MAIN OUTPUT] 0.002 % at 1 kHz, 22 Hz/22 kHz BPF |
| Dynamic range |
[MIC/LINE/Hi-Z] 106 dB, [MAIN OUTPUT] 107 dB |
[MIC/LINE/Hi-Z] 106 dB, [MAIN OUTPUT] 107 dB |
[MIC/LINE/Hi-Z] 102 dB, [MAIN OUTPUT] 105 dB |
[MIC/LINE/Hi-Z] 102 dB, [LINE IN 5-6] 106 dB, [MAIN OUTPUT] 105 dB |
| Gain range |
54 dB (Hi-Z: 39.5 dB) |
54 dB |
54 dB |
54 dB |
| Power requirements |
DC5 V/0.5 A |
DC5 V/0.5 A |
DC5 V/0.9 A |
DC5 V/1.5 A |
| Power consumption |
2.5 W |
2.5 W |
4.5 W |
7.5 W |
| Dimensions |
W |
158 mm (6.2") |
158 mm (6.2") |
159 mm (6.3") |
252 mm (9.9") |
| H |
47 mm (1.9") |
47 mm (1.9") |
47 mm (1.9") |
47 mm (1.9") |
| D |
102 mm (4.0") |
102 mm (4.0") |
159 mm (6.3") |
159 mm (6.3") |
| Net weight |
450 g (1.0 lb) |
450 g (1.0 lb) |
1.0 kg (2.0 lb) |
1.5 kg (3.3 lb) |
| Included Accessories |
UR22MK3 UR12MK3 Setup Guide, Cubase AI License Card, Steinberg Plus License Card, USB 2.0 Cable (USB Type-C to Type-A, 1.5 m) |
UR22MK3 UR12MK3 Setup Guide, Cubase AI License Card, Steinberg Plus License Card, USB 2.0 Cable (USB Type-C to Type-A, 1.5 m) |
Setup Guide, Cubase AI License Card, Basic FX Suite License Card, Steinberg Plus License Card, USB Cable (3.1 Gen1, Type-C to Type-A, 1.0 m) |
Stetup Guide, Cubase AI License Card, Basic FX Suite License Card, Steinberg Plus License Card, USB Cable (3.1 Gen1, Type-C to Type-A, 1.0 m), AC Adaptor (PA-150B) |
| Operating temperature |
0 to + 40 ℃ |
0 to + 40 ℃ |
0 to + 40 ℃ |
0 to + 40 ℃ |
| Outline |
| Mixing Capacity |
Input Channels |
2 Mono + 1 Stereo loopback |
2 Mono + 1 Stereo loopback |
2 Mono + 3 Stereo loopback + 1 FX |
6 Mono + 3 Stereo loopback + 1 FX |
| Mix Buses |
1 |
1 |
2 (1 MIX + 1 Streaming Mix) |
3 (2 MIX + 1 Streaming Mix) |
| Stereo Buses |
1 |
1 |
1 |
2 |
| FX Buses |
- |
- |
1 |
1 |
| On-board processors |
DSP |
- |
- |
PitchFix (Voice Changer), Sweet Spot Morphing Channel Strip (Comp & EQ), Guitar Amp Classics (Amp Simulator), Ducker, Compressor, Gate, Multi-Band Compressor, Delay, REV-X (Reverb) |
PitchFix (Voice Changer), Sweet Spot Morphing Channel Strip (Comp & EQ), Guitar Amp Classics (Amp Simulator), Ducker, Compressor, Gate, Multi-Band Compressor, Delay, REV-X (Reverb) |
